Dual wavelength Waveplates
Dual wavelength waveplates are multiple order waveplate that provide a specific retardance at two different wavelengths. Its application is separation of different wavelengths with a polarization beamsplitter by rotating the polarization of one wavelength by 90°, and leaving the other unchanged.

General Specifications
Material
Quartz
Dimension tolerance
±0.1mm
Parallelism
1 arc sec
Surface quality
20-10 S/D
Wavefront distortion
λ/8@632.8nm
Retardation tolerance
λ/300
Clear aperture
>90%
Coating on both sides
R<0.25% @ design wavelength

Typical Diameters:
Φ5.0
<Φ10.0
Φ12.7
Φ15.0
Φ20.0
Φ25.4
Φ30.0
Φ38.1
Thickness: around 0.3--0.6mm

Retardation Available: λ/2, λ/4,  1λ, λ/8

Mounted Waveplates are available. (See Holder Size)




        How to order Dual Wavelength Waveplate?              Example:
Type:     Dual Wavelength
Size:     Φ25.4nm
Retardation @Wavelength-1:     λ/2@532nm
Retardation @Wavelength-2:     1λ@1064nm
Coating:     AR @1064+532nm, R<0.25%, AOI=0°

   Price on Request
   Custom Design
   Volume Discount
